F-30.2 Stream, White, Cool White LED, 12VDC Surface-Mount Linear Fixture, 26.5" Length, IP40
F-30.2 Stream, White, Cool White LED, 12VDC Surface-Mount Linear Fixture, 26.5" Length, IP40
Regular price
$112.75 USD
Regular price
Sale price
$112.75 USD
Unit price
/
per
Shipping calculated at checkout.
The F30 Series of linear LED fixtures were designed as an LED replacement for the popular Resolux 700 Series low voltage fluorescent fixtures. They deliver higher lumen output and with greater efficiency than their fluorescent predecessors.
Feature
- LED replacement for Resolux 700 Series fluorescent
- A+ Energy Efficiency rating (EU-Directive 87412012)
- Dimming compatibility with most halogen PWM digital dimmers
- Rear or surface-mount cabling
- Wide beam illumination
- UV stable PC lens will not yellow over time
- Maintenance free: No bulbs to change or store
Specifications
| Name | Description |
|---|---|
| Housing Finish/Material | Annodized aluminum/UV stable PC |
| Certifications & Compliance | CE, ROHS |
| Integrated Switch | No |
| Output Color | Cool White |
| Lifetime Hours | 30,000 hrs |
| Class | F-Rated, Class III |
| Dimmer Compatibility | PWM Digital Dimmers (e.g. Intervolt) |
| Dimmer Control Interface | N/O, Single Throw Momentary |
| Halogen Equivalency | 75+W |
| Input Voltage | 12VDC |
| Input Voltage- | 12V |
| Dimensions | 674 mm/26.54 in x 85mm/3.35 in x 22mm/0.87 in |
| Warranty | 3 Years |
| Power Consumption | 16W |
| Lens Material | PC |
| Mounting Method | Screw-mount (ss fasteners included) |
| Dimming Range | 100% |
| Light Technology | LED |
| Beam Angle | 90°+ |
| Luminous Flux | 1300 lm |
| Efficiency | 81% |
| Driver | Integrated |
| Electrical Protections | Reverse Polarity, Transient |
| Correlated Color Temperature (CCT) | 6000K |
| Color Rendering Index (CRI) | 85 |
| Ingress Protection Rating (IP) | IP20-IP55 |
| Approximate Ship Weight (lbs) | 2 |
